Fujitsu Airstage J-II Series - Page 257

Conditions
Fan speed : High
Operation mode : Heat
Reference Data
Note: Velocity distribution data based on measurements with Auto louver
grille kit installed.
z
Air velocity distribution
Side view
Vertical airow direction
louver : Down
Horizontal airow direction
louver : Center
2 (0.5)
3 (1.0)
7 (2.0)
(m)
(ft.)
0
0
1
3 7 10 13 16 20 23 26
2 3 4 5 6 7 8
30 33
9 10
(m)(ft.)
0
0
3
7
8
1
2
2.5
Unit: ft./s (m/s)
z
Air temperature distribution
Side view
Vertical airow direction
louver : Down
Horizontal airow direction
louver : Center
Unit: °F (°C)
86 (30)
82 (28)
79 (26)
75 (24)
72 (22)
(m)
(ft.)
0
0
1
3 7 10 13 16 20 23 26
2 3 4 5 6 7 8
30 33
9 10
(m)(ft.)
0
0
3
7
8
1
2
2.5
- (04-124) -
INDOOR UNITS INDOOR UNITS
