Fujitsu Airstage J-II Series User Manual

6 -7. CASSETTE TYPE (FRESH AIR)

MODELS : AUUB18TLAV, AUUB24TLAV, AUUB30TLAV,
AUUB36TLAV
z
Fresh Air volume & Static Pressure required at Fresh Air intake.
0.39 (98)
0.20 (49)
0 (0)
10
8
6
4
2
0
0 3.5 7.1 11.0 14.1 17.7 21.2 24.7
(0) (0.1) (0.2) (0.3) (0.4) (0.5) (0.6) (0.7)
Air ow [CFM (m
3
/min)]
Fresh Air
Duct static pressure [in.WG (Pa)]
Duct static pressure (mmAq)
z
Installation
Top view
9-13/16 (250)
7-5/16 (185)
1/8 (2.5) hole4
2-3/4 (70)
2-7/16 (62)
2-7/16 (62)
Fresh air inlet position (A)
View (A)
Fresh air inlet position
Refrigerant pipe Drain pipe
Fresh air inlet position
Duct ange *2
Flexible duct *2
Flexible duct *2
Fan *2
Insulation *1
Duct
(Inside Dia. ø2-3/4 (70))
Duct Fan
Unit : in. (mm)
*1 : If Fresh Air intake is used, remove insulation.
*2 : Locally purchased parts
Static pressure required at Fresh Air intake
- (04-199) -
INDOOR UNITS INDOOR UNITS
