ELECTRICAL WIRING
z
Single control
When there is a
functional earthing
Remote controller
Indoor unit
Y1
Y1
Y2
Y2
Y3
z
Multiple remote control
When there is a
functional earthing
Indoor unit
Remote
controller
Remote
controller
2Y2Y
1Y1Y
Y2 Y3Y1
z
Group control
When there is a
functional earthing
Indoor units
Remote controller
Y2
Y2 Y2 Y2 Y2Y3 Y3 Y3 Y3
Y1
Y1 Y1 Y1 Y1

DIMENSIONS
Front View Side View Rear View
[Unit : in.(mm)]
2-15/16(75)
3/4
(19)
Hole: 3/8 × 3/16
(9 × 4.5)
1-3/16
(30.0)
1-3/16
(30.0)
7/8
(23.0)
Hole: 1/4 × 3/16
(6 × 4.5)
Hole: 1/2 × 3/16
(12.5 × 4.5)
4-3/4(120)
9/16
(14.7)
3/4
(18.8)
1-9/16
(39.8)
1-3/4
(44.7)

SYSTEM DIAGRAM
z
1 remote controller
z
4 remote controllers
A , B , C , D , E : Remote controller cable.
Refer to 6-4-4 for detail specications.
A
<
=
500 m ; B+C+D+E
<
=
500 m
Indoor unit
Remote controller
A
Remote controllers
Master Slave
Indoor unit
B C
Slave
D
Slave
E
- (05 - 80) -
