z
2 remote controllers
SYSTEM DIAGRAM
z
1 remote controllers
ELECTRICAL WIRING
z
1 remote controller
REMOTE
CONTROLLER
1 2 3
1 2 3
Master
Slave
1 2 3
1 2 3 1 2 3
REMOTE
CONTROLLER
Remote controller Remote controllers
1 (RED) : 12 V
2 (WHITE) : Signal
3 (BLACK) : COM
DIMENSIONS
Front View Side View Rear View
Unit : in. (mm)
4-3/4 (120)
2-15/16 (75)
1-15/16 (49)
1-9/16 (39)
15/16 (23.5)
9/16 (14)
3/16 (4)
7/16 (11)
3/16 (4.5)
1/2 (12.5)
hole x 2
hole x 2
5/16 (8)
2-3/8 (60)
1/4 (6)
11/16 (18)
3/8 (9)
1-7/8 (47.5)
3-5/16 (83.5)
z
2 remote controllers
Indoor unit
Remote controller
A
Remote controllers
Master Slave
Indoor unit
B C
A , B , C : Remote controller cable.
Refer to chapter 6. 4-4 for detail specications.
A ≤ 1,640 ft. (500 m) ; B+C≤ 1,640 ft. (500 m)
