PACKING LIST
Name and shape Quantity Application
Remote controller cable
[33 ft. (10 m)]
1
For connecting the remote controller
Screw
(M4 × 16 mm)
2
For installing the remote controller
Cable Tie 1
For securing controller cable
Installation manual 1
Operating manual 1
WIRING SPECIFICATIONS
Use Size Wire type Remarks
Remote controller cable
22AWG
(0.33
mm
2
)
Polar 3 core Use sheathed PVC cable.
SPECIFICATIONS
Model name UTY - RHK
Dimensions [H × W × D]: in. (mm) 4-3/4 × 2-15/16 × 9/16 (120 × 75 × 14)
Weight: oz. (g) 3 (90)
- (05 - 86) -
CONTROL
SYSTEM
CONTROL
SYSTEM
