Fujitsu Airstage J-II Series User Manual


ELECTRICAL WIRING
Connection cable A
[L = 16 ft. (5 m)]... Standard accessory
Connection cable C
[L = 33 ft. (10 m)]... Optional service parts
Connection cable
[L = 5-7/8 in. (150 mm)]
...Standard accessory *1
Indoor unit control box
PC board
Connected to
PC board *2
Connected to
IR Receiver unit
IR Receiver unit
Connected to
Connection cable
2-3/8 in. × 4-3/4 in.
(60 mm × 120 mm)
hole
*1 Connection cable Connection cable D
*2 Connected to PC board CN18

DIMENSIONS
7/16
(11.5)
5/16 (8.5)
5-11/16 (145)
3-9/16 (90)
3/4
(18.5)
2-3/8 (60)
2-1/4 (57.6)
3-5/16 (83.5)
7/8 (22.9)
4-11/16 (118.4)
2-7/8 (72.4)
9/16 (13.6) 9/16 (13.6)
2-1/4 (57.4)
5/16 (7.2) 5/16 (7.2)
11/16 (17)
Front View Side View
Rear View
Unit: in. (mm)
