INSTALLING THE CONTROLLER UNIT
Remote controller
cable
Transmission
cable
Cable of refrigerant pressure
sensor (accessories)
Cable tie
(accessories)
Fix the cable with cable tie using 3 xing holes.
Fix the connection cable even outside this product as necessary.
Holes for fixing cable tie (3 places)
Cable tie (accessories)
- (05 - 108) -
CONTROL
SYSTEM
CONTROL
SYSTEM
