DIMENSIONS
ELECTRICAL WIRING
Unit : in. (mm)
NOTES:
● Do not run power cable and transmission cable together, electrical
interference will cause communication errors.
● Use shield cable for transmission cable. The shield metal should be
grounded.
● Do not forget to ground the Network Convertor.
Power supply
Transmission cable to
L
ON
W
ORKS
®
network
Network convertor
Transmission cable to
VRF network
8-5/16 (211)
9-1/2 (241.6)
11-5/16 (288)
2-Ø5 (3/16)
2-5/8
(67)
3-1/2
(89.5)
3-1/2
(89.5)
1-1/8
(29)
Ø1-1/8 (28)
For dust proof
bushing
4 - Ø3/16 (5) For M4x20mm screws
Ø 1-1/8(28)
For dust proof bushing
For M4x20mm
screws
10-11/16 (272) Hole pitch
Hole pitch
3-3/4 (95)3-3/4 (95)
Hole pitch
Ø7/8 (22.2) For conduit
FUSE (3A)
OUTDOOR UNIT
SWITCH
TRANSMISSION CABLE
TRANSMISSION
CABLE
General purpose building control computer
(L
ONWORKS Device)
POWER SUPPLY CABLE
MASTER
OR
SLAVE
OUTDOOR
UNIT
Router
(Locally purchased)
®
1Φ 50/60Hz
208-240V
VRFLON
NETWORK CONVERTOR
INDOOR UNIT
INDOOR UNIT
B1 B2 X1 X2
(Disconnect switch)
- (05 - 142) -
CONTROL
SYSTEM
CONTROL
SYSTEM
