TC : Total Capacity kBtu/h.
IP : Input Power kW (Compressor + Outdoor fan motor).
The data is based on the following conditions. Pipe length : 25 ft. (7.5 m) , Height dierence : 0 ft. (0 m).
COOLING CAPACITY
in kBtu/h
MODEL : AOU48RLAVM
z
Capacity : 48 kBtu/h (4 ton)
Total rated
cooling capacity
of indoor unit
Outdoor
temperature
Indoor temperature
68
°F
DB 59
°F
WB 73
°F
DB 61
°F
WB 75
°F
DB 63
°F
WB 79
°F
DB 64
°F
WB 80
°F
DB 67
°F
WB 82
°F
DB 68
°F
WB 86
°F
DB 72
°F
WB 90
°F
DB 73
°F
WB
(°FDB) TC IP TC IP TC IP TC IP TC IP TC IP TC IP TC IP
62.4
(130%)
23
39.6 1.92 45.3 2.18 51.0 2.44 53.9 2.57 62.4 2.95 64.7 3.05 67. 8 3.09 68.5 3 .10
32
39.6 1.92 45.3 2.18 51.0 2.44 53.9 2.57 62.4 2.95 64.7 3.05 67. 8 3.09 68.5 3 .10
41
39.6 1.92 45.3 2.18 51.0 2.44 53.9 2.57 62.4 2.95 64.7 3.05 67. 8 3.09 68.5 3 .10
50
39.6 1.92 45.3 2.18 51.0 2.44 53.9 2.57 62.4 2.95 64.7 3.05 67. 8 3.09 68.5 3 .10
59
39.6 1.92 45.3 2.18 51.0 2.44 53.9 2.57 62.4 2.95 64.5 3.09 6 7.3 3.18 68.0 3.20
70
39.6 1.96 45.3 2.31 51.0 2.70 53.9 2.91 61.5 3.49 62.2 3.51 64.9 3.60 65.6 3.62
73
39.6 2.05 45.3 2.43 51.0 2.84 53.9 3.06 60.8 3.61 61.5 3.63 64.3 3.71 65.0 3.73
77
39.6 2 .19 45.3 2.60 51.0 3.04 53.9 3.27 60.0 3.76 60.7 3.78 63.4 3.86 6 4.1 3.89
81
39.6 2.34 45.3 2.77 51.0 3.24 53.9 3.49 59.2 3.91 59.8 3.93 62.6 4.02 63.3 4.04
86
39.6 2.53 45.3 3.00 51.0 3.51 53.9 3.78 58 .1 4.10 58.8 4.12 61.5 4.21 62.2 4.23
91
39.6 2.73 45.3 3.24 51.0 3.79 53.9 4.09 5 7.0 4.30 5 7.7 4.32 60.4 4.39 61.1 4.41
95
39.6 2.91 45.3 3.45 51.0 4.03 53.9 4.35 56.2 4.45 56.9 4.47 59.6 4.56 60.3 4.59
99
39.6 3.09 45.3 3.66 51.0 4.30 53.4 4.57 55.3 4.64 56.0 4.66 58.7 4.76 59.4 4.78
104
39.6 3.33 45.3 3.97 51.0 4.67 52.3 4.81 54.3 4.88 55.0 4.90 57. 6 4.99 58.2 5.00
109
39.6 3.61 45.3 4.31 50.6 5.00 51.0 5.00 52.5 5.00 53.0 5.00 55.1 5.00 55.6 5.00
115
39.6 3.97 43.4 4.50 45.7 4.50 46.2 4.50 47. 6 4.50 48.1 4.50 50.1 4.50 50.6 4.50
57.6
(120%)
23
36.5 1.78 41.8 2.02 47.1 2.26 49.7 2.38 57. 6 2.73 60.3 2.85 66.3 3.07 67.0 3.08
32
36.5 1.78 41.8 2.02 47.1 2.26 49.7 2.38 57. 6 2.73 60.3 2.85 66.3 3.07 67.0 3.08
41
36.5 1.78 41.8 2.02 47.1 2.26 49.7 2.38 57. 6 2.73 60.3 2.85 66.3 3.07 67.0 3.08
50
36.5 1.78 41.8 2.02 47.1 2.26 49.7 2.38 57. 6 2.73 60.3 2.85 66.3 3.07 67.0 3.08
59
36.5 1.78 41.8 2.02 47.1 2.26 49.7 2.38 57. 6 2.73 60.3 2.85 65.9 3 .14 66.6 3 .16
70
36.5 1.82 41.8 2.08 47.1 2.43 49.7 2.61 57. 6 3.20 60.3 3.41 63.6 3.56 64.3 3.58
73
36.5 1.88 41.8 2.19 47.1 2.56 49.7 2.75 57.6 3.36 60.3 3.58 63.0 3.67 63.7 3.69
77
36.5 1.99 41.8 2.35 47.1 2.73 49.7 2.94 57.6 3.59 59.5 3.74 62.2 3.83 62.9 3.85
81
36.5 2.12 41.8 2.50 47.1 2.91 49.7 3.13 5 7. 6 3.83 58.7 3.90 61.3 3.98 62.0 4.00
86
36.5 2.29 41.8 2.71 47.1 3.15 49.7 3.39 57. 0 4.07 5 7.6 4.09 60.3 4.17 61.0 4.19
91
36.5 2.48 41.8 2.93 47.1 3.41 49.7 3.67 55.9 4.26 56.6 4.28 59.2 4.36 59.9 4.38
95
36.5 2.63 41.8 3.11 47.1 3.63 49.7 3.90 5 5 .1 4.42 55.8 4.44 58.4 4.53 59.1 4.55
99
36.5 2.80 41.8 3.30 47.1 3.85 49.7 4.15 54.3 4.60 54.9 4.63 57. 6 4.72 58.2 4.74
104
36.5 3.01 41.8 3.57 47.1 4.19 49.7 4.51 53.3 4.84 53.9 4.86 56.5 4.96 57. 2 4.98
109
36.5 3.26 41.8 3.88 47.1 4.54 49.7 4.90 51.7 5.00 52.2 5.00 54.2 5.00 54.7 5.00
115
36.5 3.59 41.8 4.27 43.8 4.50 4 5 .1 4.50 46.5 4.50 46.9 4.50 48.8 4.50 49.3 4.50
52.8
(110%)
23
33.5 1.64 38.3 1.86 43.2 2.08 45.6 2 .19 52.8 2.52 55.2 2.63 64.6 3.05 65.3 3.06
32
33.5 1.64 38.3 1.86 43.2 2.08 45.6 2 .19 52.8 2.52 55.2 2.63 64.6 3.05 65.3 3.06
41
33.5 1.64 38.3 1.86 43.2 2.08 45.6 2 .19 52.8 2.52 55.2 2.63 64.6 3.05 65.3 3.06
50
33.5 1.64 38.3 1.86 43.2 2.08 45.6 2 .19 52.8 2.52 55.2 2.63 64.6 3.05 65.3 3.06
59
33.5 1.64 38.3 1.86 43.2 2.08 45.6 2 .19 52.8 2.52 55.2 2.63 64.4 3.09 65 .1 3.11
70
33.5 1.68 38.3 1.90 43.2 2 .17 45.6 2.33 52.8 2.83 55.2 3.01 62.2 3.51 62.9 3.53
73
33.5 1.73 38.3 1.97 43.2 2.28 45.6 2.45 52.8 2.98 55.2 3.17 61.6 3.63 62.2 3.65
77
33.5 1.81 38.3 2.10 43.2 2.44 45.6 2.62 52.8 3.18 55.2 3.39 60.8 3.78 61.4 3.80
81
33.5 1.91 38.3 2.25 43.2 2.60 45.6 2.79 52.8 3.40 55.2 3.61 60.0 3.94 60.6 3.96
86
33.5 2.07 38.3 2.43 43.2 2.82 45.6 3.03 52.8 3.68 55.2 3.91 58.9 4.13 59.6 4.15
91
33.5 2.23 38.3 2.63 43.2 3.05 45.6 3.27 52.8 3.98 55.2 4.23 5 7.9 4.32 58.6 4.34
95
33.5 2.37 38.3 2.79 43.2 3.24 45.6 3.48 52.8 4.23 54.5 4.40 57.1 4.48 5 7.7 4.50
99
33.5 2.52 38.3 2.96 43.2 3.44 45.6 3.69 52.8 4.52 53.8 4.59 56.3 4.67 56.9 4.70
104
33.5 2.71 38.3 3.20 43.2 3.73 45.6 4.01 52 .1 4.80 52.8 4.82 55.3 4.91 55.9 4.94
109
33.5 2.93 38.3 3.47 43.2 4.04 45.6 4.35 50.9 5.00 51.4 5.00 53.3 5.00 53.8 5.00
115
33.5 3.22 38.3 3.81 43.2 4.45 43.3 4.50 4 6.1 4.50 46.6 4.50 48.4 4.50 48.9 4.50
48.0
(100%)
23
30.5 1.51 34.8 1.70 39.2 1.90 41.4 2.00 48.0 2.30 50.2 2.40 59.0 2.80 61.2 2.90
32
30.5 1.51 34.8 1.70 39.2 1.90 41.4 2.00 48.0 2.30 50.2 2.40 59.0 2.80 61.2 2.90
41
30.5 1.51 34.8 1.70 39.2 1.90 41.4 2.00 48.0 2.30 50.2 2.40 59.0 2.80 61.2 2.90
50
30.5 1.51 34.8 1.70 39.2 1.90 41.4 2.00 48.0 2.30 50.2 2.40 59.0 2.80 61.2 2.90
59
30.5 1.51 34.8 1.70 39.2 1.90 41.4 2.00 48.0 2.30 50.2 2.40 59.0 2.80 61.2 2.90
70
30.5 1.54 34.8 1.74 39.2 1.95 41.4 2.06 48.0 2.49 50.2 2.65 59.0 3.31 61.2 3.48
73
30.5 1.59 34.8 1.80 39.2 2.03 41.4 2.17 48.0 2.62 50.2 2.78 59.0 3.48 60.6 3.60
77
30.5 1.66 34.8 1.88 39.2 2.17 41.4 2.32 48.0 2.80 50.2 2.98 59.0 3.71 59.8 3.75
81
30.5 1.73 34.8 2.00 39.2 2.31 41.4 2.48 48.0 2.99 50.2 3.17 58.4 3.89 59.0 3.91
86
30.5 1.85 34.8 2.17 39.2 2.50 41.4 2.68 48.0 3.24 50.2 3.44 5 7. 4 4.08 58.0 4.10
91
30.5 2.00 34.8 2.34 39.2 2.70 41.4 2.90 48.0 3.50 50.2 3.72 56.4 4.28 57. 0 4.30
95
30.5 2.12 34.8 2.49 39.2 2.87 41.4 3.08 48.0 3.73 50.2 3.95 55.6 4.43 56.2 4.45
99
30.5 2.25 34.8 2.64 39.2 3.05 41.4 3.27 48.0 3.96 50.2 4.21 54.8 4.62 55.5 4.65
104
30.5 2.42 34.8 2.84 39.2 3.29 41.4 3.53 48.0 4.31 50.2 4.58 53.9 4.86 54.5 4.88
109
30.5 2.61 34.8 3.08 39.2 3.57 41.4 3.83 48.0 4.67 50.2 4.97 52.2 5.00 52.7 5.00
115
30.5 2.87 34.8 3.38 39.2 3.93 41.4 4.22 43.0 4.50 44.4 4.50 46 .1 4.50 46.5 4.50
