SYSTEM DIAGRAM
PACKING LIST
Name and shape Quantity Application
WHITE-USB-KEY
(software protection key with software)
1
Includes the software and manuals for Service Tool.Additionally, it
works as the software protection key.
Software protection key to be connected to an USB port on the PC
that the Service Tool is installed. Service Tool runs only on a PC with
this WHITE-USB-KEY.
OTHER REQUIRED DEVICES (Locally purchased)
● Personal computer that satisfies the following system requirements
● Echelon
®
U10 USB Network Interface – TP/FT-10 Channel (Model number: 75010R) (Required
for each VRF Network.)
VRF network system
USB Adaptor
(Locally
purchased)
Personal Computer
(Locally purchased)
Personal Computer
(Locally purchased)
Software &
protection key for
Service Tool *
(UTY-ASGXZ1)
VRF System SideRemote Side
Internet
Up to 1 PC
can be connected simultaneously.
*
WibuKey of UTY-ASGX can be used.
