Fujitsu Airstage J-II Series User Manual

4-2-2. MODEL: UTY-AMGX

SYSTEM DIAGRAM
z
System components
VRF network system
USB Adaptor
Personal Computer
(Locally purchased)
Software
(UTY-AMGX)
Personal Computer
(Locally purchased)
Software
Protection Key
VRF System SideMonitoring Side
Internet
or
Public Telephone LIne
z
Support 4 VRF network system
PC USB adaptor (max. 4 adaptors per PC) permit control and monitoring of up to 1,600 units.
Suitable for large-scale buildings or hotels
Max. 400
indoor unit
Max. 400
indoor unit
Max. 400
indoor unit
Max. 400
indoor unit
VRF network
system 1
VRF network
system 2
VRF network
system 3
VRF network
system 4
USB Adaptor
Personal Computer
(Locally purchased)
- (05 - 197) -
