1. SYSTEM DESIGN
1-1. REFRIGERANT SYSTEM
CONNECTABLE UNIT WITHIN 1 REFRIGERANT SYSTEM
Unit Quantity Remarks
Outdoor unit 1 unit
Indoor unit
1 to Max. 6 units 3 ton (AOU36RLAVM)
1 to Max. 8 units 4 ton (AOU48RLAVM)
1 to Max. 9 units 5 ton (AOU60RLAVM)
z
Table
Ton
Capacity
(Btu/h)
Outdoor unit
quantity
Maximum
connectable
indoor unit
Connectable
capacity range
3 36,000 1 6
50% to 130%4 48,000 1 8
5 60,000 1 9
z
Caution
●
When all indoor units are operating at maximum capacity, individual indoor unit operate at a
slightly lower capacity. (When connecting more than 100%)
●
Do not exceed both of "connectable capacity range" and "maximum connectable indoor
unit", otherwise it may cause hinder the return of the refrigerant oil and cause a compressor
breakdown.
●
Minimum connectable indoor unit number is 1.
- (06 - 01) -
