THE MAXIMUM WIRING LENGTH OF UNIT
Name Model Maximum wiring length ft. (m)
Network convertor
UT Y-VGGX Z1
UT Y-VTGX
Remote controller to Network convertor 328 (100)
Used for single split
Airconditioner
Indoor unit to Network convertor 328 (100)
Signal amplier UTY-VSGXZ1 In each network segment 1,640 (500)
External switch
controller
UT Y-TERX
UT Y-TEK X
External switch to UTY-TERX, UTY-
TEKX
164 (50)
Max.connectable 16 indoor
units.
2 Remote controllers can be
used jointly.
Indoor unit to UTY-TERX,
UT Y-TEK X
82 (25)
Wired, Simple remote
controller
UT Y-RNRUZ2
UT Y-RNKU
UT Y-RSKU
UT Y-RHKU
UT Y-RSRY
UT Y-RHRY
Remote controller cable 1,640 (500)
