COOLING CAPACITY TABLE
z
Outdoor unit
Ton
Cooling
capacity
(Btu/h)
Model name
3 36,000 AOU36RLAVM
4 48,000 AOU48RLAVM
5 60,000 AOU60RLAVM
z
Indoor unit
Type
Cooling capacity
(Btu/h)
Model name
Compact
Cassette
4,000 AUUA4TLAV
7,5 0 0 AUUA7TLAV
9,500 AUUA9TLAV
12,000 AUUA12TLAV
14,000 AUUA14TLAV
18,000 AUUA18TLAV
24,000 AUUA24TLAV
Circular ow
cassette
18,000 AUUB18TLAV1
24,000 AUUB24TLAV1
30,000 AUUB30TLAV1
36,000 AUUB36TLAV1
48,000 AUUB48TLAV1
Cassette
18,000 AUUB18TLAV
24,000 AUUB24TLAV
30,000 AUUB30TLAV
36,000 AUUB36TLAV
Mini duct 4,000 ARUL4TLAV1
Slim Duct /
Slim
Concealed
Floor
7,5 0 0 ARUL7TLAV
9,500 ARUL9TLAV
12,000 ARU L12TL AV
14,000 A RU L14TL AV
18,000 A RU L18T L AV
Medium Static
Pressure Duct
24,000 ARUM24TLAV
30,000 ARUM30TLAV
36,000 ARUM36TLAV
High Static
Pressure Duct
36,000 ARUH36TLAV
48,000 ARUH48TLAV
60,000 ARUH60TLAV
Type
Cooling capacity
(Btu/h)
Model name
Vertical Air
Handler
12,000 ARUV12TLAV
18,000 ARUV18TLAV
24,000 ARUV24TLAV
30,000 ARUV30TLAV
36,000 ARUV36TLAV
48,000 ARUV48TLAV
60,000 ARUV60TLAV
Compact oor
4,000 AGUA4TLAV1
7,5 0 0 AGUA7TLAV1
9,500 AGUA9TLAV1
12,000 AGUA12TL AV1
14,000 AGUA14TL AV1
Floor / Ceiling
12,000 A BUA12TL AV
14,000 ABUA14TLAV
18,000 ABUA18TL AV
24,000 ABUA24TLAV
Ceiling
30,000 ABUA30TLAV
36,000 ABUA36TLAV
Wall Mounted
4,000 ASUA4TLAV1
7,5 0 0
ASUA7TLAV1
ASUA7TLAV
9,500
ASUA9TLAV1
ASUA9TLAV
12,000
ASUA12TL AV1
ASUA12TL AV
14,000
ASUA14TL AV1
ASUA14TL AV
18,000
ASUB18TLAV1
ASUB18TLAV
24,000
ASUB24TLAV1
ASUB24TLAV
30,000 ASUB30TLAV1
34,000 ASUB36TLAV1
- (06 - 19) -
