WIRED REMOTE CONTROLLER (2-WIRE) WIRING
SPECIFICATION
Note: UTY-RNRUZ2 only
Maximum connectable number of remote controllers by cable size and the length.
Cable size Max.connectable number of remote controllers
AWG mm
2
*L ≤ 328 ft. (100 m)
328 ft. (100 m) < *L ≤
820 ft. (250 m)
820 ft. (250 m) < *L ≤
1,640 ft. (500 m)
16 1.25 4 4 4
18 0.75 (1.25 > *S ≥ 0.75) 4 4 2
20 0.5 (0.75 > *S ≥ 0.5) 4 2 2
22 0.3 (0.5 > *S ≥ 0.3) 4 1 1
*L: Total cable length, *S: Cable size
