SLIM DUCT / SLIM CONCEALED FLOOR TYPE
Name and shape Q'ty Application
Operating
manual
1
Installation
manual
1
Installation template
1
For positioning the
indoor unit
Washer
8
For installing indoor unit
Pipe Insulation
(Large)
1
For indoor piping
connection
(Large pipe)
Pipe Insulation
(Small)
1
For indoor piping
connection
(Small pipe)
Cable Tie(s)
Medium
4
For cutting opening.
Large
4
For securing the power
supply, transmission
cable and remote control
cable. Do not run power
cable and transmission
cable together, electrical
interference will cause
communication errors.
Name and shape Q'ty Application
Filter (Small)
2
(AR07/09/
12/14)
Filter (Big)
2
(AR18)
Drain hose
1
For securing the
refrigerant connection
hose.
Band
1
For installing drain hose
Drain hose insulation B
1
Insulates the drain hose
