FUNCTION SETTING
1) After verifying that the system is operating normally, press the MODE/EXIT button (SW107)
once.
LED105 LED104
LED105 LED104
2) Press the SELECT button (SW108), and display “F2” on the LED104.
LED105 LED104LED105 LED104 LED105 LED104 LED105 LED104
*1 *1
(Monitoring mode) (Setting mode) (Function mode) (Error history mode)
(The display of the LED104 changes each time when the SELECT button is pressed.)
*1:The “F1”and “F9” modes are used for maintenance, so do not set them in regular operation.
3) When “F2” appears on the LED104, press the ENTER button (SW109).
A ashing display appears on the LED105, and the ashing display of “F2” on the LED104
changes to the illuminated display of a number.
LED105 LED104
LED105 LED104
4) Referring to the Settings List shown below, press the SELECT button (SW108) and display the
code number of the mode you want to set on the LED105.
Ex.) To select switching between Forced Stop and Emergency Stop
LED105 LED104
LED105 LED104
Next, press the ENTER button (SW109), and conrm the selection of the mode you want to
set.
LED105 LED104 LED105 LED104
A ashing display on the LED105 changes to an illuminated display, and an illuminated display
on the LED104 changes to a ashing display.
- (07 - 59) -
