Fujitsu Airstage J-II Series User Manual

LED105
CODE No.
Setting Mode
LED104
CODE No.
Setting Function
Factory
setting
Outdoor unit
Remarks
Master Slave
2 8
Change of unit
(Temperature)
0 0 Celsius (°C)
l
¡ ¡
0 1 Fahrenheit (°F)
2 9
Change of unit
(Pressure)
0 0 MPa
l
¡ ¡
0 1 psi
3 0
Energy saving
level setting
0 0 Level 1 (stop)
l
¡
-
*1
The capacity limit can be
selected by the external
input terminal (CN133) when
operating with the “Energy
Saving Peak Cut function.”
The lower the level, the more
the e󰀨ect of energy saving, but
the cooling/heating performance
will also drop.
0 1
Level 2 (operated at
40% capacity)
0 2
Level 3 (operated at
60% capacity)
0 3
Level 4 (operated at
80% capacity)
0 4
Level 5 (operated at
100% capacity)
3 1 Prohibited
0 0 Prohibited
l
Setting prohibited
0 1 Prohibited
4 0
Capacity
priority setting
(in low noise
mode)
0 0 O󰀨 (quiet priority)
l
¡
-
*1
If the cooling/heating
performance becomes
insu󰀩cient when the low noise
mode is set, it is possible to
set “capacity priority” that
automatically cancels the low
noise mode (once performance
is restored, the mode will
automatically return to the low
noise mode).
0 1 On (capacity priority)
4 1
Low noise
mode setting
0 0 O󰀨 (Normal)
l
¡
-
*1
0 1 On (Low noise mode)
4 2
Low noise
mode
operation level
setting
0 0 Level 1 (55dB)
l
¡
-
*1
The noise level when operating
in the low noise mode can be
set.
0 1 Level 2 (50dB)
6 0
Back up
operation
0 0 On
l
¡
-
*1
0 1 O󰀨
7 0
Electricity meter
No. setting 1
*2
0 0 Setting number x00
l
¡ ¡
Set the ones digit and tens digit
of the No. of the electricity meter
connected to CN135.
0 1 Setting number x01
▪ ▪ ▪
▪ ▪ ▪
▪ ▪ ▪
9 8 Setting number x98
9 9 Setting number x99
7 1
Electricity meter
No. setting 2
*2"
0 0 Setting number 0xx
l
¡ ¡
Set the hundreds digit of the
No. of the electricity meter
connected to CN135.
0 1 Setting number 1xx
0 2 Setting number 2xx
*1: Do not set this for outdoor units with Slave setting.
*2: When electricity meter No. is set to “000” and “201 to 299”, the pulses input to CN135 become ine󰀨ective.
Available setting number is "001" to "200"
- (07 - 68) -
