SWITCH TABLE
DIP-SW
type A SET1
1 Prohibited
2 Prohibited
3 Prohibited
type B SET2
1 Operation mode selecting switch 1
2 Operation mode selecting switch 2
3 Cool/heat selection control time switch 1
4 Cool/heat selection control time switch 2
Rotary
SW
type C
RB AD
x 1
RB unit address switch 1
RB AD
x 10
RB unit address switch 2
REF AD
x1
Refrigerant circuit address switch 1
REF AD
x10
Refrigerant circuit address switch 2
DIP SWITCH SETTING
z
SET1 setting
●
SET1-1, SET1-2, SET1-3 setting prohibited
(
u
...Factory setting)
SET1-1 SET1-2 SET1-3
u
OFF OFF OFF Fixed at OFF
ON ON ON Setting prohibited
z
SET2 setting
●
Operation mode selecting switch
(
u
...Factory setting)
SET2-1 SET2-2 Description Remarks
u
OFF OFF
Priority given to the rst
command
Priority is given to the operation mode which is set
rst.
ON OFF
Priority given to external input
of RB unit
Priority is given to the operation mode which is set by
the external input terminal (CNA01 or CNA02).
OFF ON
Priority given to administrative
indoor unit
Priority is given to the operation mode of the
administrative indoor unit which is set by the wired
remote controller
ON ON Setting prohibited
- (07 - 117) -
FUNCTION
SETTING
FUNCTION
SETTING
