Fujitsu Airstage J-II Series User Manual

2. OUTDOOR UNIT BRANCH KIT

UTP-DX567A
NOTE: Only for VR-II series.
z
Port diameters
Liquid pipe Discharge gas pipe
Q'ty Q'ty
1 1
Suction gas pipe
Q'ty
1
z
Heat insulation
Heat insulation Application
Q'ty
3
for Liquid pipe
× 1
for Discharge
gas pipe × 1
for Suction gas
pipe × 1
Unit: in. (mm)
L-joint pipe
Q'ty 2
ø1/2 (12.70)
ø1/2 (12.70)
ø5/8 (15.88)
ø5/8 (15.88)
ø3/4 (19.05)
ø3/4 (19.05)
ø1/2 (12.70)
L-joint pipe
Q'ty 2 Q'ty 2
Q'ty 2
ø7/8 (22.22)
ø7/8 (22.22)
ø7/8 (22.22)
ø7/8 (22.22)
ø1-1/8 (28.58)
ø1-1/8 (28.58)
ø1-3/8 (34.92)
ø5/8 (15.88)
ø5/8 (15.88)
ø5/8 (15.88)
ø3/4 (19.05)
ø3/4 (19.05)
ø3/4 (19.05)
L-joint pipe
Q'ty 2 Q'ty 2
Ø7/8 (22.22)
Ø7/8 (22.22)
Ø7/8 (22.22)
Ø1-3/8 (34.92)
Ø1-3/8 (34.92)
Ø1-5/8 (41.27)
Ø1-1/8 (28.58)
Ø1-1/8 (28.58)
Ø1-1/8 (28.58)
Ø1-1/8 (28.58)
Tape
Q'ty
8
- (10 - 16) -
OPTIONAL PARTS OPTIONAL PARTS
