Fujitsu Airstage J-II Series User Manual


UTP-CX567A
NOTE: Only for V-II series.
z
Port diameters
Liquid pipe Gas pipe
Q'ty Q'ty
1 1
z
Heat insulation
Heat insulation Application
Q'ty
2
for Liquid pipe
× 1
for Gas pipe
× 1
z
Dimensions
Liquid pipe Gas pipe
L-joint pipe
Q'ty 2
ø1/2 (12.70)
ø1/2 (12.70)
ø5/8 (15.88)
ø5/8 (15.88)
ø3/4 (19.05)
ø3/4 (19.05)
ø1/2 (12.70)
L-joint pipe
Q'ty 2 Q'ty 2
Ø7/8 (22.22)
Ø7/8 (22.22)
Ø7/8 (22.22)
Ø1-3/8 (34.92)
Ø1-3/8 (34.92)
Ø1-5/8 (41.27)
Ø1-1/8 (28.58)
Ø1-1/8 (28.58)
Ø1-1/8 (28.58)
Ø1-1/8 (28.58)
Tape
Q'ty
8
L-joint pipe
2-15/16 (75)
13/16 (20)
2 (50)
9-5/16 (237)
6-3/16 (157)
12-13/16 (325)
L-joint pipe
5-7/8 (150)
4-3/4 (120)
13/16 (20)
13/16 (20)
3-9/16 (90)
19-3/16 (488)
9-7/16 (239)
4-3/4 (120)
14-1/2 (369)
Unit: in. (mm)
- (10 - 18) -
OPTIONAL PARTS OPTIONAL PARTS
