AIR FILTER

AIR FILTER
● UTD-LF25NA (2pcs.) ● UTD-LF60KA (2pcs.)
● For Medium Static Pressure Duct type ● For High Static Pressure Duct type
19-15/16 (507)
9-7/16 (239)
16-15/16 (430)
12-11/16 (332)
PULL
„‚o‚oƒ?@‚X‚R‚V‚Q‚O‚R‚Q‚w‚w‚w

FLANGE (Square)

FLANGE (Round)
● UTD-SF045T ● UTD-RF204 (4pcs.)
● For Medium Static Pressure Duct type ● For Medium Static Pressure Duct type
● For Ceilimg type
32 -
Ø
3/16(5)
holes
1-9/16
(40)
43-1/16 (1,093)
9-3/16
(234)
Ø9-1/4 (235)
Ø7-11/16 (195)
Ø8-1/16 (205)
3-3/8 (85)
Ø8-7/8 (225)

DRAIN PUMP UNIT

DRAIN PUMP UNIT
● UTR-DPB24T, UTZ-PU1EBA
● UTZ-PU1NBA
● For Duct type
● For Ceiling type
Unit: in. (mm)
- (10 - 58) -
