Fujitsu Airstage J-II Series User Manual


MODEL: UTZ-PU1EBA
z
Application indoor units
Type Model name
Ceiling ABUA30TLAV, ABUA36TLAV
z
Installing drain pump unit & Electrical wiring
z
Installing pipe
Drain pump wire
(Connector: Blue)
Drain hose B
Drain hose A
Drain pump assy
Drain pan assy
Float switch wire
(Connector: Red)
To indoor unit
circuit board
59-1/16in. to 78-3/4in.
(1.5 to 2.0m)
Max 19-11/16in.
(500mm)
Supports
Rise Trap Air Vent
Prohibited Prohibited Prohibited
- (10 - 65) -
