DIMENSIONS
Unit: in. (mm)
22-7/16 (570)
Min .17-11/16 (450)
4-1/4 (108)
3-15/16 (100)
1-3/4 (45)
10-1/8 (257)
7-15/16 (201)
22-7/16 (570)
26-7/8 (683)
15-3/8 (390)
4-3/4 (120)
5-7/8 to 7-7/8
(150 to 200)
12-15/16 (328)
15-11/16 (398)
12-3/16
(310)
Ceiling opening space
Inspection hatch
(TOP VIEW)
(SIDE VIEW)
(SIDE VIEW)
• When installing this kit, inspection hatch is necessary. (It is necessary when servicing.)
- (10 - 69) -
