DIMENSIONS
Unit: in. (mm)
• When installing this kit, inspection hatch is necessary. (It is necessary when
servicing.) Either one of inspection hatches must be installed.
33-1/16 (840)
17-11/16 (450)
Inspection hatch
15-3/4 to 17-11/16
(400 to 450)
17-11/16 (450)
2-3/16 (55)2-3/16 (55)
2-3/4
(70)
33-1/16 (840)
4-3/4
(120)
11-5/16
(
288
)
16-7/16
(
418
)
14-13/16
(
376
)
9-11/16
(
246
)
2-13/16
(71)
36 (914)
3-15/16 (100)
□
Min.
Inspection hatch
□
Min.
(TOP VIEW)
(SIDE VIEW)
*: The size is di󰀨erent according to indoor unit used.
(SIDE VIEW)
Standard type * Slim type *
- (10 - 76) -
