USING SETUP MODE
5-56 User's Manual
Table 5.7 CONFIG Items and Options (Cont.)
NOTE: Underlined options are the factory defaults.
CONFIG
Items
Options Description
GATHER Setting of ribbon protective control
at a line feed on continuous forms
ENABLE The protective control is executed.
DISABLE The protective control is not
executed.
CUT-CTL Setting of retracting control at
canceling TEAR OFF of continuous
forms.
PRCISIN The precision-prioritized retracting
control is executed.
It retracts a certain amount of paper
(the top part of the paper which
hangs out from the TOFS), and then
moves back to the position before
TEAR OFF. If TOFS detects paper
end when a certain amount of paper
is retracted, it executes the
continuous forms save operation
and then executes the paper loading
operation.
SPEED The speed-prioritized retracting
control is executed.
It retracts the paper by the amount
the paper was advanced.
