USING SETUP MODE
5-60 User's Manual
Table 5.7 CONFIG Items and Options (Cont.)
NOTE: Underlined options are the factory defaults.
CONFIG
Items
Options Description
<RL-CENT> Selection of the print carrier position
when paper is fed via a front path (with
feeding of continuous forms paper from
the rear and use of a rear CSF)
POSN1 Position 1: Column 31
POSN2 Position 2: Column 42
<SKEWCNT> Detection of paper feed skew
PRCISIN Enables paper feed skew detection.
Precision is the first priority.
SPEED Enables paper feed skew detection.
Speed is the first priority.
DISABLE Disables paper feed skew detection.
<FF-CODE> Selection of the method of processing
for the FF code is received in cut sheet
mode or for the “LF/FF” switch
EJECT Ejects cut sheets.
FORM-FD Uses a page break.
<CSFBIN1> Selection of the CSF for bin 1 if both a
front CSF and rear CSF are mounted
FRONT Front CSF
REAR Rear CSF
To Next Page
