System expansions
Removing the casing cover
► Switch the device off.
The device must not be in the energy-saving mode!
► If there is a foot installed, remove it.
► Remove any plugged-in wires which are in the way.
1
2
a
► Raise the clip (a), hold it in this position and pull the casing cover in the direction of the arrow (1).
► Lift the casing cove r off the casing (2).
34 Fujitsu
