System expansio ns
Opening and closing the drive cage
To be able to install and remove drives in the m iddle and lower bays, it is
necessary to fold the drive cage upwards.
Opening the drive cage
► Remove the casing cover (see chapter "Removing the c asing cover", Page 34).
a
1
2
► Press the release (a) in the direction of the a rrow (1).
► Fold the drive cage fully open (2) until it locks in pla ce.
Fujitsu 45
