System expansio ns
Installing and removing WLAN an
tennas
If you have installed a suitable low-profi le board, you can install and remove the
associated WLAN antennas as described below.
Operation of WLAN antennas is not permitted in Taiwan.
Installing WLAN antennas
• A suitable low-profile board is installed (see chapter "Installing and removing
low-profile boards", Page 60).
1
2
3
3
► Working in the direction of the arrow (1), place the WLAN antennas onto
the plug-in positions of the board (2).
► Secure the WLAN antennas by turning i n the direction of the arrow (3).
► Align the WLAN a ntennas as required.
