Fujitsu ESPRIMO D7 Series - Technical Specification

Technical specification
Technical specification
Electrical data
Safety standards complied w ith: IEC 60950-1, CSA 6095 0-1, UL
60950-1, EN 55022 class B,
EN 55024, EN 61 000-3 -2/-3-3
Protection class: I
Rated voltage range: 100-240V
Rated freque ncy:
50-60Hz
Max. rated current
E85+:
Device without monitor socket:
3,0-2,0 A
E90+:
Device with monitor socket:
of which Value for monitor socket:
5,3-3,5 A
2,0-1,0 A
E94+:
Device with monitor socket:
of which: Value for monitor socket:
5,0-2,5 A
2,0-1,0 A
Dimensions
Width/depth/height: 332 mm x 338 mm x 89 mm /
13.07 in x 13.31 in x 3.50 in
Weight
In basic configuration: approx. 8 kg / 17.64 lbs
Environmental conditions
Environment class (3K2):
Environment class (2K2):
DIN IEC 721 part 3-3
DIN IEC 721 part 3-2
Temperature:
Operating (3K2): • ESPRIMO D556 / D756 / D757 /
D956 / D957:
10°C ... 35°C /5 0°F ... 95°F
• ESPRIMO D956 LL:
5°C ... 40°C /41 °F ... 104°F
Transportation (2K2): –25°C to 60°C /–13°F ... 140°F
The for
mation of condensation is not permitted while the d evice is in operation !
Clear
ance required to ensure adequate ventilation:
Witho
ut air vents
With
air vents
min. 10 mm / 0.39 in
min. 200 mm / 7.87 in
