System expansio ns
1
► Slide the drive with the EasyChange rails into the bay (1). Check that the component side of
the drive faces downwards towards the base of the casing (with the drive cage closed).
► Connect the cables
at the d rive and at the mainboard. Make sure the polarity is correct.
► Fold the drive cage into the closed position again (see c hapter "
Closing the drive cage", Page 46).
► Fit the casing cov
er back on to the casing (see Chapter "
Reattaching the casing cover.", Page 35).
If necessary, y
ou must adjust the entry for the drive accordingly in the BIOS Setup.
Fujitsu 51
