20 Operating manual RX100 S5
Technical data Preface
1.5 Technical data
Electrical data
Rated voltage range 100 V - 127 V or 200 V - 240 V
Frequency 50 Hz - 60 Hz
Rated current in the basic configuration 100 V - 240 V / 1.8 A - 0.8 A
Max. rated current 100 V - 240 V / 4 A - 2 A
Effective power 177 W
Apparent power 183 VA
Heat dissipation 637 kJ/h (604 btu/h)
Main power fuse 16 A (6.3 A)
Protection class I
