RX100 S5 Operating manual 61
Starting up and operation Controls and indicators
5.1.2 Rear of server
Indicators on connection panel (Global Error indicator and CSS indicator)
Figure 13: Global Error indicator and CSS indicator
1 CSS/Global Error indicator (yellow/red)
Generally, the three possible states of this indicator have the following
meanings:
– Does not light up when the system is OK.
– If the event is still acute after a power failure, the indicator is activated
after the restart.
– Lights up when a prefailure event was detected. The indicator also
lights up in standby mode.
– Flashes when an error was detected. The indicator also flashes in
standby mode.
For more details on the indicated errors, you can consult the System
Event Log (SEL), the ServerView Local Service Panel, ServerView S2 or
the ServerView Remote Management via iRMC's own Web server.
1
!
CSS
