90 Operating manual RX100 S5
Replacement of non-hot-plug components CSS components
8.2.2.2 Installing a new memory module
V CAUTION!
Please note the equipping rules in the tecnical manual for the system
board D2542.
Figure 24: Installing a memory module
Ê Carefully press the memory module into the slot (1) until the fastening tabs
on both sides of it engage (2).
2
2
1
