Fujitsu Primergy RX100 S5

98 Operating manual RX100 S5
Replacement of non-hot-plug components CSS components
8.2.4.4 Installing a riser module
Figure 32: Installing a riser module
Ê Insert the riser card into the system board slot (1).
Make sure that the pins of the riser holder fit into the corresponding
openings (2).
1
1
2 2
2
2
