Fujitsu Primergy RX100 S5 User Manual

RX100 S5 Operating manual
Contents
1 Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.1 Concept and target groups for this manual . . . . . . . . . . 7
1.2 Documentation overview . . . . . . . . . . . . . . . . . . . . 8
1.3 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.4 Notational conventions . . . . . . . . . . . . . . . . . . . . 19
1.5 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . 20
2 Installation steps, overview . . . . . . . . . . . . . . . . . . 23
3 Important information . . . . . . . . . . . . . . . . . . . . . 25
3.1 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . 25
3.2 CE conformity . . . . . . . . . . . . . . . . . . . . . . . . . 32
3.3 FCC Class A Compliance Statement . . . . . . . . . . . . . 33
3.4 Transporting the server . . . . . . . . . . . . . . . . . . . . 34
3.5 Rack installation instructions . . . . . . . . . . . . . . . . . 35
3.6 Environmental protection . . . . . . . . . . . . . . . . . . . 36
4 Hardware installation . . . . . . . . . . . . . . . . . . . . . . 39
4.1 Unpacking the server . . . . . . . . . . . . . . . . . . . . . 40
4.2 Installing/removing the server in/from the rack . . . . . . . 41
4.2.1 Rack requirements . . . . . . . . . . . . . . . . . . . . . . . 42
4.2.2 Installation in PRIMECENTER/DataCenter rack . . . . . . . . . 45
4.2.3 Installation in 3rd party racks . . . . . . . . . . . . . . . . . . 48
4.2.4 Inserting the server . . . . . . . . . . . . . . . . . . . . . . . 49
4.3 Connecting devices to the server . . . . . . . . . . . . . . . 51
4.3.1 Connecting the monitor . . . . . . . . . . . . . . . . . . . . . 52
4.4 Connecting the server to the mains . . . . . . . . . . . . . . 53

Fujitsu Primergy RX100 S5 Specifications

General

Processor cache	1 MB
Processor cores	2
Processor family	Intel Pentium Dual Core
Processor frequency	2.2 GHz
Processor cache type	L2
Processor front side bus	800 MHz
Number of processors installed	1
Hot-swap	Yes
HDD interface	Serial ATA
Optical drive type	DVD Super Multi
Total storage capacity	0 GB
Memory slots	4
Internal memory	1 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	1 x 1 GB
Networking features	Gigabit Ethernet
USB 2.0 ports quantity	5
Ethernet LAN (RJ-45) ports	3
Power supply	350 W
Power requirements	100 - 127V/200 - 240V@50 - 60Hz
Redundant power supply (RPS) support	No
Dimensions (WxDxH)	430 x 560 x 42.5 mm
Compatible operating systems	Microsoft Windows Server 2008/Server 2003, NovellSUSE Linux Enterprise Server, Red Hat Enterprise Linux
Chassis type	Rack (1U)
Operating temperature (T-T)	15 - 35 °C
Operating relative humidity (H-H)	10 - 85 %
Certification	GS CE CSAc/us ULc/us FCC Class A CB RoHS WEEE VCCI CCC C-Tick BSMI

Weight and Dimensions

Weight	12000 g
