RX100 S5 Operating manual 91
CSS components Replacement of non-hot-plug components
8.2.3 Replacing a system fan
V CAUTION!
Since the system fans are not redundant, defective system fans have to
be replaced immediately.
Figure 25: Example: removing system fan 5 (FAN 5)
Ê Lift off the system fan upwards (1).
To do this, press up the four rubber pins (a).
1
a
a
a
a
