Fujitsu Primergy RX100 S5

RX100 S5 Operating manual 97
CSS components Replacement of non-hot-plug components
8.2.4.3 Installing a new expansion card
Figure 31: Installing a new expansion card
Ê Carefully press the new expansion card into the riser card slot (a), until it
clicks into place (1).
Make sure that the lug on the slot cover clicks into place in the corre-
sponding hole (2).
a
1
2
