56 Operating manual RX100 S5
Controls and indicators Starting up and operation
5.1.1.1 Controls
ID ID button
Lights up (blue) on the front and on the rear of the server when the
ID button is pressed. The two ID indicators are synchronized.
On/Off button
When the system is switched off, it can be switched on again by
pressing the On/Off button. When the system is operating, pressing
the On/Off button will switch off the system.
I The On/Off button does not disconnect the server from the
mains voltage. To disconnect from the mains completely,
remove the power plug(s).
RST Reset button
Pressing the reset button reboots the system.
V CAUTION!
Risk of loss of data!
NMI NMI button
V CAUTION!
Do not press! Risk of loss of data!
The NMI button may only be used by service.
