RX100 S5 Operating manual 87
CSS components Replacement of non-hot-plug components
8.2 Replacement of non-hot-plug components
When a defective non-hot-plug component has been detected (see page 58 or
page 62), proceed as follows:
Ê Exit all applications and shut down the server properly (see section
“Switching the server on and off” on page 65).
Ê Pull all power plugs out of the insulated sockets of the rack's internal power
supply.
Ê Remove the server from the rack (see section “Installing/removing the server
in/from the rack” on page 41) and put the server on a table, for example.
8.2.1 Opening the server and identifying the defective
CSS component
Figure 21: Loosening the knurled screw
Ê Unlock the top cover, by loosening the knurled screw on the rear panel (1).
1
