58 Operating manual RX100 S5
Controls and indicators Starting up and operation
CSS CSS/Global Error indicator (yellow/red)
Generally, the three possible states of this indicator have the
following meanings:
– Does not light up when the system is OK.
– If the event is still acute after a power failure, the indicator is
activated after the restart.
– Lights up when a prefailure event was detected. The indicator
also lights up in standby mode.
– Flashes when an error was detected. The indicator also
flashes in standby mode.
For more details on the indicated errors, you can consult the
System Event Log (SEL), the ServerView Local Service Panel,
ServerView S2 or the ServerView Remote Management via
iRMC's own Web server.
Depending on the color, the states „light up“ and „flash“ have the
following meanings:
–CSS (yellow)
Lights up yellow if a prefailure event was detected for a CSS
component.
Flashes yellow if an error was detected that you can fix
yourself with the CSS concept (see “Customer Self Service
(CSS)” on page 10).
– Global Error (red)
Lights up red if a prefailure event was detected for a non-CSS
component.
Flashes red if an error was detected for a service incident.
– CSS/Global Error (yellow/red)
Lights up and/or flashes alternately yellow and/or red if
several prefailure events and/or errors were detected at the
same time (see above).
!
