RX100 S5 Operating manual 95
CSS components Replacement of non-hot-plug components
8.2.4 Replacing an expansion card
8.2.4.1 Removing a riser module
Figure 29: Removing a riser module
Ê Remove the cables from the defective expansion card.
Ê Undo the two knurled screws (1).
Ê Carefully pull out the riser module upwards (2).
2
11
