Fujitsu Primergy RX100 S5

RX100 S5 Operating manual 55
5 Starting up and operation
V CAUTION!
Follow the safety instructions in chapter “Important information” on
page 25.
5.1 Controls and indicators
5.1.1 Front of server
Figure 11: Controls and indicators on the front panel
1 ServerView Local Service Display 6 NMI button
2 ID button 7 Power-on indicator
3 ID indicator 8 Hard disk activity indicator
4 Reset button 9 CSS/Global Error indicator
5 On/Off button 10 DVD drive activity indicator
ID
!
RST
CSS
NMI
12
3
4
5
678910
