Fujitsu Primergy RX100 S5 User Manual

Operating manual RX100 S5
Contents
4.5 Instructions for connecting/disconnecting cables . . . . . . 54
5 Starting up and operation . . . . . . . . . . . . . . . . . . . . 55
5.1 Controls and indicators . . . . . . . . . . . . . . . . . . . . . 55
5.1.1 Front of server . . . . . . . . . . . . . . . . . . . . . . . . . . 55
5.1.1.1 Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
5.1.1.2 Indicators on the control panel . . . . . . . . . . . . . . . . 57
5.1.1.3 Indicators on the accessible drives/components . . . . . . . 59
5.1.2 Rear of server . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
5.2 Switching the server on and off . . . . . . . . . . . . . . . . 65
5.3 Configuring the server . . . . . . . . . . . . . . . . . . . . . 67
5.3.1 Hard disk drive write cache . . . . . . . . . . . . . . . . . . . . 67
5.3.2 Configuring the onboard SATA controller . . . . . . . . . . . . . 68
5.3.3 Configuring the onboard SAS controller with “Integrated
Mirroring Enhanced” . . . . . . . . . . . . . . . . . . . . . . . 68
5.3.4 Configuration with ServerStart . . . . . . . . . . . . . . . . . . 69
5.3.5 Configuration without ServerStart . . . . . . . . . . . . . . . . 70
5.4 Cleaning the server . . . . . . . . . . . . . . . . . . . . . . . 70
6 Property and data protection . . . . . . . . . . . . . . . . . . 71
6.1 BIOS Setup security functions . . . . . . . . . . . . . . . . . 71
7 Troubleshooting and tips . . . . . . . . . . . . . . . . . . . . 73
7.1 Power-on indicator remains unlit . . . . . . . . . . . . . . . . 73
7.2 Server switches itself off . . . . . . . . . . . . . . . . . . . . 74
7.3 Screen remains blank . . . . . . . . . . . . . . . . . . . . . . 74
7.4 Flickering stripes on monitor screen . . . . . . . . . . . . . 75
7.5 No screen display or display drifts . . . . . . . . . . . . . . . 75
7.6 No mouse pointer displayed on screen . . . . . . . . . . . . 75
7.7 Incorrect date and time . . . . . . . . . . . . . . . . . . . . . 76
7.8 System will not boot . . . . . . . . . . . . . . . . . . . . . . . 76
7.9 Error message on screen . . . . . . . . . . . . . . . . . . . . 76

Fujitsu Primergy RX100 S5 Specifications

General

Processor cache	1 MB
Processor cores	2
Processor family	Intel Pentium Dual Core
Processor frequency	2.2 GHz
Processor cache type	L2
Processor front side bus	800 MHz
Number of processors installed	1
Hot-swap	Yes
HDD interface	Serial ATA
Optical drive type	DVD Super Multi
Total storage capacity	0 GB
Memory slots	4
Internal memory	1 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	1 x 1 GB
Networking features	Gigabit Ethernet
USB 2.0 ports quantity	5
Ethernet LAN (RJ-45) ports	3
Power supply	350 W
Power requirements	100 - 127V/200 - 240V@50 - 60Hz
Redundant power supply (RPS) support	No
Dimensions (WxDxH)	430 x 560 x 42.5 mm
Compatible operating systems	Microsoft Windows Server 2008/Server 2003, NovellSUSE Linux Enterprise Server, Red Hat Enterprise Linux
Chassis type	Rack (1U)
Operating temperature (T-T)	15 - 35 °C
Operating relative humidity (H-H)	10 - 85 %
Certification	GS CE CSAc/us ULc/us FCC Class A CB RoHS WEEE VCCI CCC C-Tick BSMI

Weight and Dimensions

Weight	12000 g
