22 Operating manual RX100 S5
Technical data Preface
Mechanical values
Weight
Approx. 11 kg (depending on configuration).
Ventilation clearance
At least 200 mm on the front and rear
Ambient conditions
Condensation during operation must be avoided!
Noise level
Width 430 mm
Depth 560 mm
Height 42.5 mm or 1 HU
Environment class 3K2
Environment class 2K2
EN 60721 / IEC 721 Part 3-3
EN 60721 / IEC 721 Part 3-2
Temperature:
Operation (3K2) 15 °C ... 35 °C
Transport (2K2) -25 °C ... 60 °C
Humidity 10% ... 85%
Sound power level L
WAd
(ISO 9296) < 4.9 B (standby)
< 6.1 B (operation)
Sound pressure level at adjacent workstation
L
pAm
(ISO 9296)
< 34 dB (A) (standby)
< 46 dB (A) (operation)
