Fujitsu ScanSnap S300 User Manual

196
4. Rotate the pick roller bushing (left).
5. Remove the pick roller with its shaft.
Slightly pull up the left part of the Pick roller shaft (about 5mm), move it towards the left
side, and then raise it to remove from the scanner.
ATTENTION
If the around the pick roller is dirty by paper-powder, it may cause a scanning
error. Remove the dirt using a dry cloth moistened with Cleaner F1.
* Don't use water, mild detergent or air-spray.
Pick roller bushing
Pick roller
Pick roller shaft
Pick roller shaft
Pick roller

Fujitsu ScanSnap S300 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 360 mm
Scanner type	Sheet-fed scanner
Sensor type	CIS
Minimum scan area (ADF)	50.8 x 50.8 mm
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto document feeder (ADF) input capacity	10 sheets
Bundled software	ScanSnap Manager V4.2, ScanSnap Organizer V3.2, CardMinder V3.2
Scan media weight	64 - 104.7 g/m²
Dimensions (WxDxH)	284 x 95 x 77 mm
Power requirements	AC 100V to 240V, 50 / 60 Hz
Dimensions (W x D x H) (imperial)	11.18 x 3.74 x 3.03 \
Maximum scan area (ADF) (imperial)	8.5 x 14.17 \
Minimum scan area (Auto Document Feeder)	2 x 2 \
Minimum RAM	512 MB
Minimum storage drive space	920 MB
Compatible operating systems	Windows 2000 Professional, Windows XP, Windows Vista
Power supply type	AC/USB
Power consumption (standby)	5 W
Power consumption (typical)	9 W
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Certification	RoHS

Weight and Dimensions

Weight	1400 g
