20
4. Attach Inlet Water Tubing: Push one end of one of the two (2) silicone water tubes onto the
water pump tting. Now attach the other end of that tubing to the “water inlet” located at the back of
machine. Completely submerge the assembled water pump in the bucket of distilled water.
Water Line
Water In
Water Out
Figure 3.9
Figure 3.10
