MAINTENANCE VTG-IOM-2016-1214 SECTION 4
! WARNING
All information in this manual is for
reference and guidance purposes,
and does not substitute for required
professional training, conduct,
and strict adherence to applicable
jurisdictional/professional codes and
regulations.
4 CAUTION
All maintenance procedures should
be completed by trained personnel.
Appropriate training and instructions
are available from the Fulton Service
Department at (315) 298-5121 or
your local Fulton Heating Solutions
Representative.
The VTG-2000 through VTG-5000 Fulton part numbers are
2-22-000570 (socket) and 2-22-000571 (adapter). For VTG-6000,
the socket part number is is 2-22-000572. It is a 1
1/16 Deep
Well Socket that does not require an adapter like the VTG-2000
through VTG-5000 model sizes.
½” drive torque wrench and extension (U.S. only; provided by
service technician)
NOTE: Do not loosen or remove the upper doors without guidance from the
factory with regards to proper procedures for accessing the reside of the heat
exchanger.
3. Proceed as follows based on model size:
VTG-2000
through
VTG-5000
Sizes Only:
Evenly tighten all 4 nuts on the upper door in ve stages,
in a criss-cross pattern: top left, bottom right, bottom left,
top right (see Figure 24), in the following order:
20 ft/lbs (27.1 NM)
35 ft/lbs (47.4 NM)
50 ft/lbs (67.8 NM)
100 ft/lbs (135.5 NM)
130 ft/lbs (176.2 NM)
Recheck all nuts in a circular pattern, and proceed to step
4.
VTG-6000
Size Only:
See Figure 25. Evenly tighten all 5/8 numbered nuts (1-20)
as follows, in the sequence illustrated:
25 ft/lbs (33.9 NM)
50 ft/lbs (67.8 NM)
75 ft/lbs (101.6 NM)
100 ft/lbs (135.5 NM)
Recheck all at 100 ft/lbs (135.5 NM), and proceed to step
4.
4. Verify settings of the lower door. The lower door is retained by (16) 3/8”
bolts. Tools required for lower door setting verication:
9/16” socket and 3/8” drive wrench (U.S. only; provided by
service technician)
5. Evenly tighten all nuts on the lower door to 23 ft/lbs (31.2 NM) in a criss-
cross pattern. See Figure 24 and Figure 25. Do not over torque, as this can
result in damaging of the door seal.
