3.1 T
erminal unit, IC-215
3-6
** Handl
ing flat cable connector
**
Fig.3.1.10 Connect
or allocation
Note 1) Disconnecting flat cable from J6
T
o disconnect the flat ca
ble, gently
, set the locking tab to ve
rtical position and then pull
out the cable
from the connector
. Excess force will damag
e the connector ta
b. T
o
connect the cable, reverse the above procedure.
J9
note2)
J6
note1)
FDD connector
Fig.3.1.1
1 Flat
cable connector
, J6
p.c.b
J6
Flat cabl
Slowly
57
59
